"Deposit and Dispense Bills" Large Capacity Multi-Cassette Bill Recycler
G750 Bill Recycling Unit
A NEW ERA OF CASH CYCLE MANAGEMENT
Product Outline
- Advanced bill transport technology developed through Fujitsu‘s long experience
- Capacity: 12,800 notes / recycle & deposit, 14,000 notes / dispense
- Simultaneous validation of 256 denominations, a world‘s best
- Feeding mechanism of Patrol note detects remaining objects in transport paths
Main Features
Advanced technology & high performance
- Bill transport technology developed through Fujitsu‘s experienced analysis of banknote conditions and operations accomplishes high-speed & steady currency handling
- Compact cabinet can hold as many as 12,800 notes for recycle & deposit use, 14,000 notes for dispense use
- Pocket-shaped note accepter is capable of accepting and dispensing maximum 200 notes in a bunch
State-of-the-art bill validation
- New sensors and new image-processing algorithm, achieving significantly advanced banknote authentication and fitness
- Simultaneous validation of 256 denominations, a world‘s best
- Counterfeit note detection and deposit/dispensing control by comparing banknote serial numbers against database through all transactions
Easy operability & maintenance
- Easy to remove jammed banknotes by accessing all the transport paths
- Feeding mechanism of Patrol note detects remaining objects in transport paths
Specifications
378mm x 725mm x 828mm
Cradle and shutter are included.
Approx. 158kg
Cradle and shutter are included.
Front or Rear
4 recycling cassettes + 1 reject cassette
7 notes / Second *
*It depends on the size and condition of notes.
Max. 77mm x 162mm
Min. 63mm x 130mm
Approx. 12,800 new notes (Recycle & Deposit use)
4 recycling cassettes + 1 reject cassette
- recycling cassette: Approx. 2,700 new notes
- reject cassette: Large area: Approx. 1,800 new notes
Small area: Approx. 200 new notes
Approx. 14,000 new notes (Dispense use only)
4 recycling cassettes + 1 reject cassette
- recycling cassette: Approx. 3,000 new notes
- reject cassette: same as above
CEN/XFS 3.1Compatible
USB 2.0 Full speed
DC +24V (+10%, -8%)
Max. 33.0A
Ave. 24.5A
Operation 0 ºC - 50 ºC
Stop State -5 ºC - 50 ºC
Operation 20 ~ 80%RH
Stop State 10 ~ 90%RH
Note 1: Above specifications may be changed without prior notice.
Note 2: You may need to check beforehand whether the cash handling machine can handle your banknotes (including polymer notes) even if they are within the specified media range.
