Advanced Media Dispensing Unit
F510 Bill Dispensing Unit
World-proven performance Powerful Multi-Cassette Media Dispensing Unit
Product Outline
- F510 is an advanced media dispenser with high speed, large capacity, and reliable stability.
- Expandable up to 5 cassettes, 3,000 notes/cassette.
- Support major currencies.
Main Features
- 3,000 notes per cassette, expandable up to 5 cassettes, 15,000 notes in all
- Front or rear access configuration
- Bill retract function
- RS232C interface
- Advanced remote diagnosties to help detect problems
Specifications
274mm x 752mm x 810mm (Front Access)
274mm x 757mm x 810mm (Rear Access)
Approx. 72kg
Front or Rear
Up to 5 Cassettes
7 notes / Second *
*It depends on the size and condition of notes.
Max. 82mm x 172mm
Min. 60mm x 120mm
0.07 - 0.18 mm
60 notes / Transaction
Yes / Bunch Presenter
Option
Note storage area: 370mm
New US Note 3000 each cassette (Approx.)
Integrated in 1st Cassette
Approx. 150 Bills
Adjustable - Factory Set
Approx. 100 Notes
RS232C
DC +24V +-10%
Max. 10A
Ave. 4A
Operation 0 ºC - 40 ºC
Stop State -5 ºC - 50 ºC
Operation 10 ~ 85%RH
Stop State 8 ~ 95%RH
Note 1 : Above specifications may be changed without prior notice.
Note 2 : You may need to check beforehand whether the cash handling machine can handle your banknotes (including polymer notes) even if they are within the specified media range.
