Compact and Multi Cassette Media Dispenser
F56 Bill Dispensing Unit
High-end Features at low Cost Flexible, Easy Integration
Product Outline
F56 is a compact and multi cassette media dispenser, designed for the OEM market, the Fujitsu F56 dispenser features 6 cassettes to hold up to a total of 3,000 notes or other media.
- Width 6.3in (160mm)
- Depth 15.4in (392mm)
- Height 14.8in (375mm) 2-Denominations
- Up to 500 notes / cassette
Main Features
- RS232C
- Bunch presenter
- Bill low sensor
- Denomination sensor
- Shutter (option)
- Predictive failure analysis
- Lockable cassette option
- Firmware download
- Single note reject
Specifications
2-denominations
160mm x 392mm x 375mm
Cassette: 116mm x 216mm x 98mm
Approx. 11kg
0.7kg / Cassette
Front, Rear or Dual
Up to 6 Cassettes
2 Notes / Second *
*It depends on the size and condition of notes.
Max. 82mm x 160mm
Min. 60mm x 120mm
0.09mm - 0.3mm
20 Notes / Transaction
Option
Option
Note storage area: 60mm
New US Note 500 each cassette (Approx.)
UL, TUV certified
Max. 20 notes
Fixed sensor
Approx. 40 notes each cassette
RS232C
DC +24V +-10%
Max. 7A
Ave. 5A
Operation 0 ºC - 40 ºC
Stop State -5 ºC - 50 ºC
Operation 10 ~ 85%RH
Stop State 8 ~ 95%RH
Note 1: Above specifications may be changed without prior notice.
Note 2: You may need to check beforehand whether the cash handling machine can handle your banknotes (including polymer banknotes) even if they are within the specified media range.
