Compact and Multi Cassette Media Dispenser
F53 Bill Dispensing Unit
High-end Features at low Cost Flexible, Easy Integration
Product Outline
F53 is a compact and multi cassette media dispenser, designed for the OEM market.
Its compact body provides you with maximum flexibility and easy integration in product design.
- Width 6.3in (160mm)
- Depth 12.6in (320mm)
- Height 12.3in (313mm) 2-Denominations
- Up to 500 notes / cassette
Main Features
- RS232C
- Bill low sensor
- Denomination sensor
- Predictive failure analysis
- Lockable cassette option
- Firmware download
- Single note reject
Specifications
2-denominations
160mm x 320mm x 313mm
Cassette 116mm x 216mm x 98mm
8.5kg
0.7kg / Cassette
Front or Rear
Up to 6 Cassettes
2 notes / Second *
*It depends on the size and condition of notes.
Max. 82mm x 165mm
Min. 60mm x 120mm
0.09 - 0.3 mm
20 notes / Transaction
None
None
Accommodation 60mm
New US note 500 each cassette (Approx.)
UL, TUV certified
Max. 20 notes
Fixed sensor
Approx. 40 notes each cassette
RS232C
DC +24V +-10%
Max. 7A
Ave. 5A
Operation 0 ºC - 40 ºC
Stop State -5 ºC - 50 ºC
Operation 10 ~ 85%RH
Stop State 8 ~ 95%RH
Note 1: Above specifications may be changed without prior notice.
Note 2: You may need to check beforehand whether the cash handling machine can handle your banknotes (including polymer notes) even if they are within the specified media range.
